FEATURES:
- Housing: High grade Die-casting aluminium
- Finishes : Anodized Aluminium
- Installation Holder : Stainless Steel
- Beam Angle : 20O / 40O / 60O
- Standard Body Colour : Black
- The light transmittance of tempered glass is more than 92%
- Glueless construction waterproof design
- Rotary support with locking system
Mechanical Features:
|
Product Code |
Size (mm) (L x B x H) |
| UFL - 1210 | 100 x 100 x 105 |
| UFL - 2410 | 100 x 200 x 115 |
| UFL - 3620 | 200 x 200 x 150 |
| UFL - 4820 | 100 x 300 x 105 |
| UFL - 7230 | 200 x 300 x 155 |
| UFL - 9640 | 200 x 400 x 160 |
| UFL - 10830 | 300 x 300 x 195 |
| UFL - 14440 | 300 x 400 x 213 |
| UFL - 19240 | 400 x 400 x 249 |
SPECIFICATIONS:
| Input Voltage | : | 24 V DC / 240V AC |
| Frequency | : | 50/60 Hz |
| Power Factor @230 VAC | : | > 0.9 |
| Colour Temperatures | : | 3000 K / RGBW / RGB |
| Colour Rendering Index | : | > 80 |
| Lumen Efficacy | : | > 100 Lumens per Watt |
| Ingress Protection | : | IP66 |
| Life Span | : | 50,000 Hours |
| Safety Standard | : | IEC 60598 |
| EMC/ EMI Standard | : | IEC61547 / EN55015 |
| Harmonics | : | IEC 61000-3-2 |
OPTIONS AVAILABLE:
- Analog (1-10V) / PWM/ resistive dimming / DALI
- Surge protector upto 10KV/ 20KV
- Advance surge protector with upper and lower voltage cutoff and recovery with 20KV and phase to phase protection.
|
Product Code |
Input Power |
System Lumens |
Energy Saving |
| UFL - 1210 | 12 Watts | 1200 | 50% |
| UFL - 2410 | 24 Watts | 2400 | 50% |
| UFL - 3620 | 36 Watts | 3600 | 50% |
| UFL - 4820 | 48 Watts | 4800 | 50% |
| UFL - 7230 | 72 Watts | 7200 | 50% |
| UFL - 9640 | 96 Watts | 9600 | 50% |
| UFL - 10830 | 108 Watts | 10800 | 50% |
| UFL - 14440 | 144 Watts | 14400 | 50% |
| UFL - 19240 | 192 Watts | 19200 | 50% |
